Choose your tubes correctly.
Choose the thickness of the tubes according to your pressure usage
160 Bars [ 2300.00 PSI ]
6 mm Tube OD - Thickness 1.5 mm
8 mm Tube OD - Thickness 1.5 mm
10 mm Tube OD - Thickness 1.5 mm
12 mm Tube OD - Thickness 1.5 mm
15 mm Tube OD - Thickness 2.0 mm
18 mm Tube OD - Thickness 2.0 mm
22 mm Tube OD - Thickness 2.5 mm
28 mm Tube OD - Thickness 3.0 mm
35 mm Tube OD - Thickness 4.0 mm
42 mm Tube OD - Thickness 5.0 mm
6 mm Tube OD - Thickness 1.5 mm
8 mm Tube OD - Thickness 1.5 mm
10 mm Tube OD - Thickness 1.5 mm
12 mm Tube OD - Thickness 1.5 mm
14 mm Tube OD - Thickness 2.0 mm
16 mm Tube OD - Thickness 2.0 mm
20 mm Tube OD - Thickness 2.5 mm
25 mm Tube OD - Thickness 3.0 mm
30 mm Tube OD - Thickness 4.0 mm
38 mm Tube OD - Thickness 5.0 mm
250 Bars [ 3600.00 PSI ]
6 mm Tube OD - Thickness 1.5 mm
8 mm Tube OD - Thickness 1.5 mm
10 mm Tube OD - Thickness 1.5 mm
12 mm Tube OD - Thickness 1.5 mm
15 mm Tube OD - Thickness 2.0 mm
18 mm Tube OD - Thickness 2.0 mm
22 mm Tube OD - Thickness 2.5 mm
28 mm Tube OD - Not recommended
35 mm Tube OD - Not recommended
42 mm Tube OD - Not recommended
6 mm Tube OD - Thickness 1.5 mm
8 mm Tube OD - Thickness 1.5 mm
10 mm Tube OD - Thickness 1.5 mm
12 mm Tube OD - Thickness 1.5 mm
14 mm Tube OD - Thickness 2.0 mm
16 mm Tube OD - Thickness 2.0 mm
20 mm Tube OD - Thickness 2.5 mm
25 mm Tube OD - Thickness 3.0 mm
30 mm Tube OD - Thickness 4.0 mm
38 mm Tube OD - Thickness 5.0 mm
280 Bars [ 4000.00 PSI ]
6 mm Tube OD - Thickness 1.5 mm
8 mm Tube OD - Thickness 1.5 mm
10 mm Tube OD - Thickness 2.0 mm
12 mm Tube OD - Thickness 2.0 mm
15 mm Tube OD - Thickness 2.0 mm
18 mm Tube OD - Not recommended
22 mm Tube OD - Not recommended
28 mm Tube OD - Not recommended
35 mm Tube OD - Not recommended
42 mm Tube OD - Not recommended
6 mm Tube OD - Thickness 1.5 mm
8 mm Tube OD - Thickness 1.5 mm
10 mm Tube OD - Thickness 2.0 mm
12 mm Tube OD - Thickness 2.0 mm
14 mm Tube OD - Thickness 2.0 mm
16 mm Tube OD - Thickness 2.5 mm
20 mm Tube OD - Thickness 2.5 mm
25 mm Tube OD - Thickness 3.0 mm
30 mm Tube OD - Thickness 4.5 mm
38 mm Tube OD - Thickness 5.0 mm
300 Bars [ 4300.00 PSI ]
6 mm Tube OD - Not recommended
8 mm Tube OD - Not recommended
10 mm Tube OD - Not recommended
12 mm Tube OD - Not recommended
15 mm Tube OD - Not recommended
18 mm Tube OD - Not recommended
22 mm Tube OD - Not recommended
28 mm Tube OD - Not recommended
35 mm Tube OD - Not recommended
42 mm Tube OD - Not recommended
6 mm Tube OD - Thickness 1.75 mm
8 mm Tube OD - Thickness 2.0 mm
10 mm Tube OD - Thickness 2.0 mm
12 mm Tube OD - Thickness 2.5 mm
14 mm Tube OD - Thickness 3.0 mm
16 mm Tube OD - Thickness 4.0 mm
20 mm Tube OD - Thickness 4.0 mm
25 mm Tube OD - Thickness 4.5 mm
30 mm Tube OD - Not recommended
38 mm Tube OD - Not recommended
620 Bars [ 9000.00 PSI ]
6 mm Tube OD - Not recommended
8 mm Tube OD - Not recommended
10 mm Tube OD - Not recommended
12 mm Tube OD - Not recommended
15 mm Tube OD - Not recommended
18 mm Tube OD - Not recommended
22 mm Tube OD - Not recommended
28 mm Tube OD - Not recommended
35 mm Tube OD - Not recommended
42 mm Tube OD - Not recommended
6 mm Tube OD - Thickness 1.75 mm
8 mm Tube OD - Thickness 2.0 mm
10 mm Tube OD - Thickness 2.5 mm
12 mm Tube OD - Thickness 3.0 mm
14 mm Tube OD - Not recommended
16 mm Tube OD - Not recommended
20 mm Tube OD - Not recommended
25 mm Tube OD - Not recommended
30 mm Tube OD - Not recommended
38 mm Tube OD - Not recommended
700 Bars
[ 10,000.00 PSI ]
6 mm Tube OD - Not recommended
8 mm Tube OD - Not recommended
10 mm Tube OD - Not recommended
12 mm Tube OD - Not recommended
15 mm Tube OD - Not recommended
18 mm Tube OD - Not recommended
22 mm Tube OD - Not recommended
28 mm Tube OD - Not recommended
35 mm Tube OD - Not recommended
42 mm Tube OD - Not recommended
6 mm Tube OD - Thickness 2.25 mm
8 mm Tube OD - Thickness 2.50 mm
10 mm Tube OD - Thickness 3.00 mm
12 mm Tube OD - Thickness 3.00 mm
14 mm Tube OD - Not recommended
16 mm Tube OD - Not recommended
20 mm Tube OD - Not recommended
25 mm Tube OD - Not recommended
30 mm Tube OD - Not recommended
38 mm Tube OD - Not recommended
